Mounting the Controller
To obtain the maximum ambient temperature, you must mount the cRIO-905x in the reference
mounting configuration shown in the following image. Mounting the cRIO-905x in the
reference mounting configuration ensures that your system will operate correctly across the
full operating temperature range and provide optimal C Series module accuracy. Observe the
following guidelines to mount the cRIO-905x in the reference mounting configuration.
Figure 7. System Mounting Configuration
3
4
1
2
NI cRIO-905x User Manual | © National Instruments | 19
