National Instruments NI cRIO-905x Series - 4-Slot Controller Front Dimensions; 8-Slot Controller Front Dimensions

Figure 11. cRIO-905x 4-slot Controller Front Dimensions
1 2 3
4
221.40 mm
(8.72 in.)
89.61 mm
(3.528 in.)
Figure 12. cRIO-905x 8-slot Controller Front Dimensions
1 2 3
4 5 6 7 8
328.64 mm
(12.938 in.)
89.61 mm
(3.528 in.)
