KOMPLETEAUDIO6–Manual–39
ENGLISH
4. Plugthe1/4”TRSjackofyourheadphonesintothePHONESsocketontheKOMPLETE
AUDIO6’sfrontpanel.TurntheVolumeControlknob(VOLUME)intheheadphonesec-
tionoftheKOMPLETEAUDIO6totheleft-endstoptosetthevolumetominimum.
5. Opentheaudiopreferencesofyouraudiorecordingsoftware,andselectKOMPLETE
AUDIO6asyourinputandoutputdevice(youmayhavetorestartyourhostsoftware
forthechangestobecomeactive).Pleaserefertothedocumentationofyouraudio
recordingsoftwareforinformationonhowtoconguretheaudiodevicesetup.
6. Whilesinging/playinganinstrumentintothemicrophone,adjusttheinputsignalby
turningtherelevantinputchannel’sGAINknobgraduallytotheright.Checktheinput
LEDs(INPUT1and2onthetoppaneloftheKOMPLETEAUDIO6)tomakesureyour
inputsignaldoesnotclip;adjusttheinputlevelsothattheLEDslightgreenoninput.
A red lighting LED indicates signal clipping.
7. GraduallyturntheVolumeControlknob(VOLUME)intheheadphonesectionofthe
KOMPLETEAUDIO6totherightuntilyoureachagoodlisteninglevel.

Forinformation on how to adjust theaudioinput for recordinginyour audiorecording
software,pleaserefertoyoursoftware’sdocumentation.

Native Instruments Komplete Audio 6 Specifications

General

Audio Resolution	24-bit/192kHz
Power Supply	USB bus powered
Audio Interface Type	USB
Simultaneous I/O	6 x 6
Number of Preamps	2
A/D Resolution	24-bit/192kHz
MIDI I/O	1 x MIDI In, 1 x MIDI Out
USB	USB 2.0
Phantom Power	Yes
Digital Inputs	1 x Coax (S/PDIF)
Digital Outputs	1 x Coax (S/PDIF)
Headphone Output	1 x 1/4" TRS
Software Included	Komplete Elements
Outputs	4 x analog (2 x TRS, 2 x RCA)
