17
Nautilus® Pro Series Elliptical Assembly Manual
ASSEMBLY PROCESS
Step 10: Inspection of Assembly
10-1 Check torque at all areas highlighted below. For proper torque specifications refer to page 7 and 8 or
Steps 4, 6, and 8.
NOTE: The Pedal to Sub Pedal Arm connection is factory assembled, use #2 Phillips screwdriver to remove
plastic cover and check that bolt is tightened to proper torque..
10-2 Test machine operation at this time (not plugged in and without the console). Check for any noise from
joints, re-check torque if any noise heard.
10-3 Check alignment of pods to shrouds. If contacting shrouds, loosen misaligned nuts and adjust.
10-4 Check that machine is stable, adjust leveler feet as necessary..
