8
ASSEMBLY PROCESS
Step 1: Removing Packing & Shipping Materials
1-1 Use box knive to cut the plastic strapping and remove.
1-2 Remove the box lid and the styrofoam containing the unit covers (Figures 1 & 2).
1-3 Remove the outer box cover (Figure 3).
1-4 Use box knive to cut the shrink wrap on the left side of the unit and remove Console box (set aside). Continue
to remove the shrink wrap and the corner supports (Figure 4).
Figure 1
Figure 2
Figure 3
Figure 4
Console Box
To Next Page
