Nautilus EV716 User Manual

3
Nautilus® Pro Series Elliptical Assembly Manual
HARDWARE
Required Assembly Tools
• Torque Wrench
• 10 mm Allen Wrench
• 13 mm Box Wrench
• 19mm Socket
• 6 mm Allen Wrench
• Adjustable Wrench
• 17mm Socket
• 8 mm Allen Wrench
• Long and short #2 Phillips Screw Drivers
• 3/8” drive ratchet with 6mm, 8mm, and 10mm hex bit sockets will speed the assembly
process greatly.
Hardware Contents
Item Number Item Description Quantity
1
20mm Allen Head Bolt
4
2
1/2” Spring Washer
4
6
15mm Phillips Head Screw
36
10
70mm Hex Head Bolt
2
11
8mm Washer
4
12
M8 Locking Nut
2
14
M10 x 65mm Allen Head Bolt
6
15
M10 Washer
12
16
M10 Locking Nut
6
17
M12 x 70mm Allen Head Bolt
8
18
M12 Spring Washer
8
19
M12 x 100mm Allen Head Bolt
4
21
M12 Locking Nut
6
25
M12 x 90mm Allen Head Bolt
2
28
M8 x 40mm Allen Head Bolt
4
30
30mm Phillips Head Screw
6
34
10mm Phillips Head Screw
13
37
15mm Machine Screw
2
39
35mm Pan Head Bolt
6
42
M8 Spring Washer
4

Nautilus EV716 Specifications

General

Brand	Nautilus
Model	EV716
Category	Elliptical Trainer
Language	English
