Nautilus T616 Assembly Manual

2
Important Safety Instructions 3
Safety Warning Labels / Serial Number 6
Grounding Instructions 7
Emergency Stop Procedure 7
Specications  8
Parts 9
Hardware 10
Tools 10
Before Assembly 10
Assembly 11
Moving the Machine 22
Unfolding the Machine 23
Leveling the Machine 24
Features 25
Console Features 26
Operations 33
Getting Started 33
Power Up / Idle Mode 34
Quick Start Program 35
 UserProles  35
 ProlePrograms  37
Compare Pacer Display 41
Fitness Score Display 41
Pausing or Stopping 43
Results / Cool Down Mode 43
GOAL TRACK Statistics 43
Console Setup Mode 45
Maintenance 46
Cleaning 46
Adjusting the Walking Belt 47
Aligning the Walking Belt 47
 LubricatingtheWalkingBelt  48
Maintenance Parts 50
Troubleshooting 52
Warranty 55
Nautilus,Inc.,(800)NAUTILUS/(800)628-8458,www.NautilusInc.com-CustomerService:NorthAmerica(800)605-3369,
csnls@nautilus.com | outside U.S. technics@nautilus.com | Printed in China | © 2014 Nautilus, Inc. | ® indicates trademarks
registered in the United States. These marks may be registered in other nations or otherwise protected by common law. Nautilus,
theCamlogo,NautilusT616,NautilusTrainer,NautilusConnect,Bowex,Schwinn,andUniversalaretrademarksownedby
or licensed to Nautilus, Inc. Polar
®
, OwnCode
®
, Bluetooth
®
, iTunes
®
, Google
TM
, MyFitnessPal
®
,WD-40
®
,andLube-N-Walk
®
are
trademarks of their respective owners.
Table of ConTenTs
Tovalidatewarrantysupport,keeptheoriginalproofofpurchaseandrecordthefollowinginformation:
Serial Number __________________________
Date of Purchase ____________________
Toregisteryourproductwarranty,goto:www.nautilus.com/register
Orcall1(800)605–3369.
Ifyouhavequestionsorproblemswithyourproduct,pleasecall1(800)NAUTILUS(628–8458).

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
