Nautilus T616 Assembly Manual

11
CuttheShippingStrapontheBaseAssemblywhenithasbeenplacedintheappropriateworkspace.
1. Fold the Walking Deck on the Base Assembly
Make sure that there is safe clearance around, on and above your treadmill. Make sure there is no object to spill or cause
blockagefromthefullyfoldedposition.Besurethereisadequateheightclearancefortheraiseddeck.
Usingthesupportbarfoundbelowtherearofthewalkingbelt,liftthewalkingdeckfullyupwardandengagethehydrauliclift.
Besurethatthehydraulicliftiscorrectlylockedinplace.
Usepropersafetyprecautionsandliftingtechniques.Bendyourkneesandelbows,keepyourbackstraightandpullup
equally with both arms. Make sure that your own physical strength is capable of lifting the walking deck until it engages
thelockingmechanism.Useasecondpersonifnecessary.
Donotusethewalkingbeltorrearrollertoliftthetreadmill.Thesepartsdonotlockinplaceandcanabruptlymove.
Injurytoyouordamagetothemachinecanoccur.
Makesurethatthelockingmechanismisengaged.CarefullypullbackontheWalkingDeckandmakesurethatitdoesnot
move. When you do this, keep clear of movement path in case the treadmill lock is not engaged.
Donotleanagainstthetreadmillwhenitisfolded.Donotputitemsonitthatcouldcauseittobecomeunstableorfall.
assembly
7

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
