Nautilus T616 Assembly Manual

12
2. Connect the Input/Output (I/O) Cables and Attach the Uprights to Frame
Note:Donotcrimpcables.DonotfullytightenHardwareuntilinstructed.
3
11
B
F
X4
A
F
X4
E
E

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
