Nautilus T616 Assembly Manual

13
3. Unfold the Walking Deck
Slightly push the walking deck forward toward the front of the machine. With your left foot lightly push the top part of the
hydraulic lift forward until the locking tube releases and you can pull the walking deck slightly toward the rear of the machine.
Holduptherearofthewalkingdeck,andmovetothesideofthemachine.
Keep clear of the movement path of the walking deck.
Thehydraulicliftissetuptodroplightly.Holdontothewalkingdeckuntilapproximately2/3ofthemovementdown.Make
surethatyouuseproperliftingtechnique;bendyourkneesandkeepyourbackstraight.Thewalkingdeckcanpossiblydrop
quickly in the last part of the movement.

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
