Nautilus T616 Assembly Manual

9
Item Qty Description Item Qty Description
1 1 Console Assembly 10 1 HeartRateChestStrap
2 1 ConsoleBacking 11 1 Upright,Left
3 1 Upright,Right 12 1
HandlebarShroud, Lower Left
4 1
HandlebarShroud,UpperRight
13 1
HandlebarShroud,UpperLeft
5 1
HandlebarShroud,LowerRight
14 1 Tray, Left
6 1 BaseShroud,Right 15 1 Tray, Right
7 1
BaseAssembly
16 1 Safety Key
8 1 BaseShroud,Left 17 1
MediaCable(notshown)
9 1 Power Cord 18 1 SiliconeLubricant,Bottle(notshown)
DonotcuttheShippingStrapuntiltheBaseAssemblyhasbeenplacedintheappropriateworkspace(*).
parTs
15
14
1
3
12
13
4
5
6
7
8
11
10
9
2
16
*

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
