Nautilus T616 Assembly Manual

49
8. Connectthepowercordbackintothemachineandthenintothewalloutlet.
9. Turnonthepowertothemachinewiththepowerswitch.
10. Staytoonesideofyourmachineandstartthebeltattheslowestspeed.Letthebeltoperateforapproximately15
seconds.
Besurenottotouchthewalkingbeltorsteponthepowercord.Keepbystandersandchildrenawayfromtheproduct
you are servicing at all times.
11. Switchoffyourmachine.
12. Takecaretocleanupanyexcesslubricantfromthedeck.
Todecreasethepossibilityofslipping,besurethedeckareaisfreefromgreaseoroil.Cleanoffanyexcessoil
from the machine surfaces.

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
