Nautilus T616 Assembly Manual

53
Condition/Problem Things to Check Solution
Consoleshutsoff(enters
sleepmode)whileinuse
Checkelectrical(wall)
outlet
Make sure unit is plugged into a functioning wall outlet. Test the
outlet with a known functioning device such as a lamp.
Check connection at front
of unit
Connection should be secure and undamaged. Replace power
cord or connection at unit if either are damaged.
Check data cable integrity Allwiresinthecableshouldbeintact.Ifanyarecutorcrimped,
replace cable.
Check data cable
connections/orientation
Besurecableisconnectedsecurelyandorientedproperly.Small
latch on connector should line up and snap into place.
Reset machine Unplugunitfromelectricaloutletfor3minutes.Reconnectto
outlet.
Iftheabovestepsdonotresolvetheproblem,contactCustomer
Care for further assistance.
Fan will not turn on or will
not turn off
Reset machine Unplugunitfromelectricaloutletfor5minutes.Reconnectto
outlet.
Fan will not turn on, but
Console operates
Check for blockage of fan Unplugunitfromelectricaloutletfor5minutes.Removematerial
fromfan.Ifnecessary,detachtheConsoletohelpwithremoval.
Replace the Console if unable to remove blockage.
Unitrocks/doesnotsit
level
Check leveler adjustment Adjust levelers until machine is level.
Check surface under unit Adjustmentmaynotbeabletocompensateforextremelyuneven
surfaces. Move machine to level area.
Thumping sound when belt
operates
Walking belt Walking belt needs to be used for wear in period. Sound will go
away after the wear in period.
Walking belt not aligned Machine leveling Make sure the machine is level. Refer to the procedure for level-
ing the machine in this manual.
Walking belt tension and
alignment
Make sure the walking belt is centered and tension is correct.
Refer to the procedures for adjusting tension and aligning the belt
in this manual.
Motor sounds strained Silicone lubrication on
walking belt
Apply silicone to the inner surface of the walking belt. Refer to
the belt lubrication procedure in this manual.
Hesitationorwalkingbelt
slips when in use
Belttension Adjust the belt tension at the rear of the machine. Refer to the
procedure for adjusting belt tension in this manual.
Beltstopsmovingwhilein
use
Safety key PlugSafetyKeyintoConsole.(SeeEmergencyStopProcedure
intheImportantSafetyInstructionssection.)
Motor overload Unitmaybeoverloadedanddrawtoomuchcurrent,which
causes power to turn off to protect motor. Refer to maintenance
schedule for belt lubrication. Make sure the walking belt tension
is correct, and start unit again.
Iftheabovestepsdonotresolvetheproblem,contactCustomer
Care for further assistance.

Nautilus T616 Specifications

General

Maximum speed	19.3 km/h
Number of programs	26
Maximum user weight	136 kg
Built-in display	Yes

Weight and Dimensions

Depth	1960 mm
Width	894 mm
Height	1463 mm
Weight	97500 g
Running area (W x L)	508 x 1524 mm
