NCR SelfServ 34 ATM Installation Guide
2 B006-6590-C000
In addition to the bookset, the following publications may be required to complete the
installation:
Purpose and Audience
The Installation Bookset is intended for NCR personnel or NCR customer personnel who
are required to install the ATM.
Site Preparation
Prior to the final siting of the ATM, and before installing, ensure that the installation site
conforms to the specifications given in the publication, NCR SelfServ 34 Site Preparation
(B006-6586). In particular, ensure that the floor/plinth has been prepared and the securing
bolt holes drilled as detailed in the above publication.
Device Configuration
Device configuration is carried out using the System Application. Refer to the NCR
publication, Self-Service Support System Application User Guide (B006-6167).
Communications Configuration
If you intend to use communications, then you must configure the software and hardware.
The procedure for configuring your ATM is described in the NCR publication, APTRA
Communications Feature User’s Guide (B006-0012).
Note: Before you can start to configure the communications, you must have Self-Service
Support installed on your ATM.
For information on NCR certified communications boards, please contact your local
support representative, or refer to the following NCR Intranet site:
http://www.dundee.ncr.com/INFOPROD/Software&Services.htm
Statement Printer with Paper Stack Configuration Guide (B006-6465)
Statement Printer with Paper Roll Configuration Guide (B006-6781
)
Statement/Passbook Configuration Guide (B006-
6790)
Cash Acceptor/Recycler for ATMs Cassette Owners Guide (B006-6470
)
Envelope Deposit and Dispenser Configuration Guide (B006-6607
)
Currency Cassette Owner’s Guide (B006-1297
)
NCR SelfServ
34 Site Preparation (B006-6586)
NCR SelfServ 32, 34, 38 Site Preparation Requirements (B006-6670)
Self-Service Support System Application User Guide (B006-6167)
APTRA Communications Feature User’s Guide (B006-0012)
