NCR SelfServ 34 ATM Installation Guide
B006-6590-C000 3
System Initialization
After completing the installation and configuration of the ATM, refer to publication, Self-
Service Support, System Application User Guide (B006-6167), for details of system
initialization.
The user guide is updated frequently, therefore it is recommended that you check on the
following NCR Intranet site to ensure you have the latest version. If you are unable to get
access to the NCR Intranet, contact your local support representative for help.
http://www.dundee.ncr.com/INFOPROD/Software&Services.htm
Tools Required for Installation
When installing your ATM it is recommended that you have the following items available:
● Pincers/claw hammer to remove staples/nails from around the pallet
● Scissors
● Small flat blade screwdriver
● Security screwdriver - required to fit tamper-proof screws
● Flat blade screwdriver with 175 mm (7 in.) long blade
● Small cross head screwdriver
● Pozi drive screwdriver
● To fit security enclosure fixing bolts:
● UL - 24 mm (15/16 in.) ring/open-ended combination spanner and socket for M16
bolts
● CEN - 24 mm (15/16 in.) socket wrench for M16 bolts
● M4 monodrive security screwdriver bit (type 7), available from your NCR local
representative (part number 009-0022888) - required to fit advert window decal.
● Extraction tool (supplied with the ATM) - required to fit the card window decal
● 17 mm (11/16 in.) ring/open-ended combination spanner or socket
● Lifting/moving device. Lifting trolleys must have a maximum toe plate length of
380 mm (15.0 in.) and a minimum toe plate width of 120 mm (4.72 in.)
● Packing to protect the exterior of the ATM while on trolleys
● Hex nut driver set (including M3 and M4 sizes).
