Power Up the System
DS1000 Hardware Manual Section 3: Connecting Trunks and Extensions ◆ 3-3
3
Power Up the System
Power Up
Now that you have cabled the system, it is time to power-up.
To power up the system (Figure 3-3) and (Figure 3-4):
1. Make sure the system is properly grounded.
2. Install a surge protector in the AC outlet.
3. Plug the main cabinet’s AC power cord into its surge protector.
4. Be sure the Mode Switch is set to RUN, then turn on the cabinet’s power switch.
After a brief interval, the system will start and the power LED will flash slowly (green).
Figure 3-3: Power Switch
Figure 3-4: Power LED and Mode Switch
Power Switch
80200 -28
80200 - 14 - 1
