System Preparation and Configuration
DS1000 Hardware Manual
Section 1: Installation Basics
◆
1-1
1
Section 1: Installation
Basics
System Preparation and Configuration
System Preparation and Configuration
Unpacking
Unpack the equipment and check it against your equipment lists. Inspect for physical damage. If you are not
sure about a component’s function, review the Product Description Manual. Contact your Sales Representa-
tive if you have additional questions. Have the appropriate tools for the job on hand, including: a test set, a
punch down tool and a digital voltmeter.
Before Installing
Make sure you have a building plan showing the location of the common equipment, extensions, the telco
demarcation and earth ground. In addition, the installation site must meet the requirements outlined in the
Standard Practices Manual.
Site Requirements
The common equipment is contained in the wall-mounted Main Equipment Cabinet. Choose a central location
for the cabinet that allows enough space for the equipment — and provides enough room for you to comfortably
work. Figure 1-1
Installation Layout
on page 1-5
shows you
about
how much space your system requires.
System Configuration
Using the factory installed default configuration, your DS1000 system provides:
Turn to
Installing the Expansion Board
on page 1-10 for more on installing the Expansion PCB.
Base Expansion Total
Trunks 3 3 6
Digital Extensions 8 8 16
Analog Extensions 4 4 8
Analog Door Boxes 1 1 2
Relays 1 1 2
Page Output 1 - 1
Music Input 1 - 1
