Specifications
6-4 ◆ Section 6: Specifications and Parts DS1000 Hardware Manual
Relay Contacts
Contact Configuration: Normally open
Maximum Load: 0.5A @ 120 VAC
1A @ 24 VDC
Maximum Carry Current: 2A
Maximum Switched Voltage: 120 VAC or 60 VDC
Maximum Switched Power: 60 VA or 24 W
Minimum Switched Current: 1 mA
Minimum Switched Voltage: 1 VDC
Minimum Switched Power: 0.05 mW
Maximum Initial Contact Resistance: 100 mOhms
BGM/MOH Music Source Input
Input Impedance: 10K Ohms
Input Level: +18 dBr (+ 2 dBr) @ 1.0 Khz
REJ Recording Jack Output Specifications
Output Impedance: 200 Ohms
Output Level (into 10K Ohm load): Keyset volume setting 1 = -7.8 dBr
Keyset volume setting 7 = -5.3 dBr
The REJ broadcasts both sides of the keyset conversation (i.e., the user’s voice and the caller’s
voice) whenever the user lifts the handset. The REJ does not broadcast paging announcements or
activate for Handsfree calls.
FCC Registration Information
Model: DX7NA-624M (DS1000)
Manufacturer: NEC Infrontia
FCC Part 15 Registration: Class A
FCC Registration Number: NIFMUL-43095-KF-E
NIFMUL-43096-MF-E
Industry Canada Certificate (DOC) Number: 140-10893 A
Reg. Status FIC Mfrs. Port ID REN Network Jacks
Original 02LS2 80200 REN 0.6B RJ11C
