122
6. Connecting to Other Equipment
①HDMIcable(notsupplied)
• UseacertiedHighSpeedHDMI
®
CableorHighSpeedHDMI
®
CablewithEthernet.
• WhenconnectingtheHDMI1INorHDMI2INconnectoroftheprojectortotheBlu-rayplayer,theprojector'svideo
levelcanbemadesettingsinaccordancewiththeBlu-rayplayer'svideolevel.Inthemenuselect[ADJUST]→
[VIDEO]→[VIDEOLEVEL]andmakenecessarysettings.
②DisplayPortcable(notsupplied)
• UseacertiedDisplayPortcable.
③BNCcable(notsupplied)
• Usecablesthatare5C-FBorhigher(5C-FB,7C-FB,etc.)orBelden1694Aorhigher.Inaddition,usecableswith
acablelength100morless.
• Thelengthofcablesthatcanbeusedmaydiffer,dependingonthesignal.
④LANcable(notsupplied)
• Pleaseuseashieldedtwistedpair(STP)cableofCategory5eorhigherfortheLANcable(soldcommercially).
• TheHDBaseTportoftheprojectorsupportsHDMIsignals(HDCP)fromtransmissiondevices,controlsignalsfrom
externaldevices(serial,LAN)andremotecontrolsignals(IRcommands).
• ThemaximumtransmissiondistanceovertheLANcableis100m.(themaximumdistanceis70mfora4Ksignal)
• Pleasedonotuseothertransmissionequipmentbetweentheprojectorandtransmissionequipment.Thepicture
qualitymaybedegradedasaresult.
• ThisprojectorisnotguaranteedtoworkwithallHDBaseTtransmissiondevicessoldcommercially.
Afterturningonthepoweroftheunit,selecttheinputaccordingtotheconnectionterminal.
Inputconnector Button on the projector
cabinet
Button on the remote
control
Note
HDMI1/2IN HDMI HDMI SwitchesbetweenHDMI1andHDMI2eachtime
it is pressed.
DisplayPort1/2IN DisplayPort DisplayPort SwitchesbetweenDisplayPort1andDisplayPort2
each time it is pressed.
SDI1/2/3/4IN 3G/HD/SD-SDI AUX SwitchesbetweenSDI1,SDI2,SDI3andSDI4
each time it is pressed.
HDBaseT HDBaseT NETWORK —
