8. Appendix
1180 (46.5)
116
(4.6)
1412 (55.6)
697 (27.4)
244.5 (9.6)
278.5 (11)
519.1 (20.4)
454.6 (17.9)
64.5 (2.5)
410 (16.1)
Outline Drawing
Unit:mm(inch)
