28
2. Projecting an Image (Basic Operation)
❻ Adjusting the Picture Size and Position
Adjustingtheprojector’ssettings
[Level adjuster]
(→page29)
Adjustingtheprojectedimage’sverticalandhorizontal
position
[Lens shift]
(→page30)
Adjustingthefocus
[Focus]
(→page32)
Finelyadjustingthesizeofanimage
[Zoom]
(→page33)
Inthischapterdrawingsandcablesareomittedforclarity.
TIP:
• Built-intestpatternscanbeconvenientlyusedforadjustingthepicturesizeandposition.
 ApressoftheTESTbuttonwilldisplaythetestpattern.The◀or▶buttoncanselectonetestpattern.Toclosethetestpattern,
changethesourcetoanother.
