133
8. Appendix
3840×2160(Aspectratio:16:9)
Lens unit Drawingnumber
①② ③④
L2K-10F1 12%H 34%V
L4K-11ZM 22%H 55%V
L4K-15ZM 22%H 55%V
L4K-20ZM 22%H 55%V
L2K-30ZM 12%H 34%V
L2K-43ZM1 12%H 34%V
L2K-55ZM1 14%H 37%V
(Examplecalculation)Ifprojectingona300inchscreenusinganL4K-15ZMlensunit
Accordingtothe“Tableofscreensizesanddimensions”(→page131),H=261.5"/664.1cm,V=147.1"/373.6cm.
Adjustmentrangeintheverticaldirection:theprojectedimagecanbemovedupwards0.55×147.1"/373.6cm≈
81"/205cm,downwardsapproximately81"/205cm(whenthelensisatthecenterposition).Adjustmentrangeinthe
horizontaldirection:theprojectedimagecanbemovedtotheleft0.22×261.5"/664.1cm≈58"/146cm,totheright
approximately58"/146cm.
* Figuresdifferbyseveral%becausethecalculationisapproximate.
