59
4. Using On-Screen Menu
ROTATION
Rotates the screen within the display area.
As the angle of rotation increases, the screen becomes smaller.
ROTATION
-100 (-25°) 0 100 (25°)
RESET Returns the rotation adjustment value to the factory setting.
PINCUSHION / BARREL
Adjust this when projecting onto a cylindrical screen or spherical surface.
H PINCUSHION / BARREL
-150 (-30%) 0 300 (60%)
V PINCUSHION / BARREL
-150 (-30%) 0 300 (60%)
H KEYSTONE Example of keystone adjustment in the horizontal direction:
V KEYSTONE Example keystone adjustment in the vertical direction:
ROTATION Rotation example:
RESET Returns the adjustment value of [PINCUSHION / BARREL] to the factory setting.
NOTE:
[H KEYSTONE] or [V KEYSTONE] can be used when adjusting [H PINCUSHION / BARREL] or [V PINCUSHION / BARREL].
[ROTATION] can be used when adjusting [H KEYSTONE] or [V KEYSTONE].
Since the screen rotates within the display area, the screen becomes smaller as the rotation angle increases.
