5
1. Introduction
1-3. Part Names of the Projector
Front/Top
The lens is sold separately. The description below is for when the NP47ZL lens is mounted.
Lens
Request the dealer to attach or
detach the lens unit.
Indicator Panel
(→ page 7)
Intake vent
Takes in air to cool the projector.
(→ page xviii, 73)
Intake vent
Takes in air to cool the projector.
(→ page xviii, 73)
Remote Sensor (located on the
front and the rear)
(→ page 11)
Tilt Foot
(→ page 28)
Lens Release (PUSH) Button
Lens Cap
(The lens cap is attached to the
lens.)
To Next Page
