6
1. Introduction
Rear
Main power switch
While AC power is being
supplied, set the main power
switch to ON position (|), then
your projector will enter a
standby state.
AC IN terminal
Connect the supplied power
cord’s three-pin plug here, and
plug the other end into an ac-
tive wall outlet. (→ page 13)
Power Cord Stopper
(→ page 14)
Handle (located on 4 positions)
For transportation
NOTE:
• For moving the projector, make
sure you have at least four
people. At the same time, do
not grip and hold the projector
other than by these handles.
Attempting to move the pro-
jector with less than four
people could result in back
pain or other injuries.
Terminals
(→ page 8)
Exhaust vent
Heated aiir is exhausted from
here.
(→ page xviii, 73)
Controls
(→ page 7)
Remote Sensor
(→ page 11)
To Next Page
