NEC PX2201UL User Manual

74
7-1. Throw distance and screen size
This projector can be used with 5 kinds of optional lenses (sold separately). Refer to the information on this page and
use a lens suited for the installation environment (screen size and throw distance). Request the dealer to attach or
detach the lens unit.
Lens types and throw distance
(Unit: inch)
Screen size Lens unit model name
NP45ZL NP46ZL NP47ZL NP48ZL NP49ZL
50 40 – 51 52 – 66 63 – 86 87 – 169 170 – 295
70 56 – 70 71 – 94 91 – 118 119 – 236 237 – 417
100 75 – 102 103 – 133 126 – 169 170 – 338 339 – 594
120 91 – 122 123 – 157 154 – 204 205 – 405 406 – 712
150 115 – 153 154 – 196 189 – 255 256 – 507 508 – 889
180 138 – 185 186 – 236 229 – 307 308 – 610 611 – 1066
200 154 – 204 205 – 263 256 – 338 339 – 677 678 – 1188
250 189 – 255 256 – 330 319 – 425 426 – 846 847 –
1484
300 229 – 307 308 – 397 382 – 507 508 – 1015 1016 – 1779
(Unit: m)
Screen size Lens unit model name
(inch) (m) NP45ZL NP46ZL NP47ZL NP48ZL NP49ZL
50 1.27 1.0 – 1.3 1.3 – 1.7 1.6 – 2.2 2.2 – 4.3 4.3 – 7.5
70 1.78 1.4 – 1.8 1.8 – 2.4 2.3 – 3.0 3.0 – 6.0 6.0 – 10.6
100 2.54 1.9 – 2.6 2.6 – 3.4 3.2 – 4.3 4.3 – 8.6 8.6 – 15.1
120 3.05 2.3 – 3.1 3.1 – 4.0 3.9 – 5.2 5.2 – 10.3 10.3 – 18.1
150 3.81 2.9 – 3.9 3.9 – 5.0 4.8 – 6.5 6.5 – 12.9 12.9 – 22.6
180 4.57 3.5 – 4.7 4.7 – 6.0 5.8 – 7.8 7.8 – 15.5 15.5 – 27.1
200 5.08 3.9 – 5.2 5.2 – 6.7 6.5 – 8.6 8.6 – 17.2 17.2 – 30.2
250 6.35 4.8 – 6.5 6.5
– 8.4 8.1 – 10.8 10.8 – 21.5 21.5 – 37.7
300 7.62 5.8 – 7.8 7.8 – 10.1 9.7 – 12.9 12.9 – 25.8 25.8 – 45.2
CAUTION
• The law requires that the lens hood be mounted when using the NP49ZL lens unit in the USA or China. Be sure
to ask your dealer to mount the lens hood (model NP01LH).
TIP:
• Calculation of the throw distance from the screen size
NP45ZL lens throw distance (m) = H × 0.9 to H × 1.2 : 40"/1.0 m (min.) to 307"/7.8 m (max.)
NP46ZL lens throw distance (m) = H × 1.2 to H × 1.6 : 52"/1.3 m (min.) to 397"/10.1 m (max.)
NP47ZL lens throw distance (m) = H × 1.5 to H × 2.0 : 63"/1.6 m (min.) to 507"/12.9 m (max.)
NP48ZL lens throw distance (m) = H × 2.0 to H × 4.0 : 87"/2.2 m (min.) to 1015"/25.8 m (max.)
NP49ZL lens throw distance (m) = H × 4.0 to H × 7.0 : 170"/4.3 m (min.) to 1779"/45.2 m (max.)
“H” (Horizontal) refers to the screen width.
* Figures differ by several % with the table above because the calculation is approximate.
Ex.: Throw distance when projecting on a 100" screen using the NP47ZL lens:
According to the “Screen Size (for reference)” table (→ page 76), H (screen width) = 84.8"/215.4 cm (approx. 2.15 m).
The throw distance is 84.8"/2.15 m × 1.5 to 84.8"/2.15 m × 2.0 = 127"/3.2 m to 170"/4.3 m (because of the zoom lens).
7. Appendix
