5. Installation and Connections

① HDMI cable (not supplied)

• Use a certied High Speed HDMI

Cable or High Speed HDMI

Cable with Ethernet.

• When connecting the HDMI 1 IN or HDMI 2 IN connector of the projector to the Blu-ray player, the projector's video

level can be made settings in accordance with the Blu-ray player's video level. In the menu select [ADJUST] →

[VIDEO] → [VIDEO LEVEL] and make necessary settings.

② DisplayPort cable (not supplied)

• Use a certied DisplayPort cable.

③ BNC cable (not supplied)

• Use cables that are 5C-FB or higher (5C-FB, 7C-FB, etc.) or Belden 1694A or higher. In addition, use cables with

a cable length 100m or less.

• The length of cables that can be used may differ, depending on the signal.

④ LAN cable (not supplied)

• Please use a shielded twisted pair (STP) cable of Category 5e or higher for the LAN cable (sold commercially).

• The HDBaseT/LAN port of the projector supports HDMI signals (HDCP) from transmission devices, control signals

from external devices (serial, LAN) and remote control signals (IR commands).

• The maximum transmission distance over the LAN cable is 100 m.

• Please do not use other transmission equipment between the projector and transmission equipment. The picture

quality may be degraded as a result.

• This projector is not guaranteed to work with all HDBaseT transmission devices sold commercially.

⑤ Computer cable (mini D-sub 15 pin) (not supplied)

• Use a signal cable with ferrite core.

⑥ DVI-D cable (not supplied)

• Use a signal cable with ferrite core.
