NEC S1300 - Rear Chassis Features

Disk Array Unit Overview 1-17
Rear Chassis Features
Figure 1-8 shows the features and indicators located on the rear of the DAU.
A Controller (CONT1)
B Controller (CONT0)
C Power Supply (PS0)
D Fans (FAN0)
E Power Supply (PS1)
F Fans (FAN1)
G Service Processor (SVP)
H Battery Backup Unit (PS1)
Figure 1-8. Rear Chassis Features
A
B
C
DE
F
G
H
