Setting Up The DAU 2-5
Table 2-1. DAU and Rack Mount Parts
Reference Description Reference Description
A Disk Array Unit (DAU) F User's Guide (located on CDROM)
B Left Rail Support Hook G Power Cords (2)
C Left Rail H Countersunk Head Screws (4)
D Right Rail Support Hook I M5 Screws (4)
E Right Rail
Rack-Mount Subsystem Assembly
Before You Begin
Before you begin, please review the following cautions, warnings, and general
guidelines.
! Avoid excessive vibration and shock. Dropping an electronic component
can cause serious damage.
! Do not disconnect or remove parts other than those specified in the
procedure.
! Do not touch I/O connector pins.
! All screws are Phillips-head, unless otherwise specified.
Static Precautions
An electrostatic discharge (ESD) can damage disk drives, option boards, and
other components. You can provide some ESD protection by wearing an
antistatic wrist strap attached to chassis ground when handling DAU
components.
Electronic devices can be easily damaged by static electricity. To prevent
damage, keep them in their protective packaging when they are not installed in
the DAU.
