A-4 Controller DIP Switch Settings
The correlation between the AL-PA switch and AL-PA is shown in Table A-2.
Table A-2. AL-PA Switch Settings
AL_PA Switch AL_PA Switch AL_PA Switch AL_PA Switch
(hex) (hex) (hex) (hex) (hex) (hex) (hex) (hex)
EF 00
E8 01
E4 02 B1 21 72 40 3C 5F
E2 03 AE 22 71 41 3A 60
E1 04 AD 23 6E 42 39 61
E0 05 AC 24 6D 43 36 62
DC 06 AB 25 6C 44 35 63
DA 07 AA 26 6B 45 34 64
D9 08 A9 27 6A 46 33 65
D6 09 A7 28 69 47 32 66
D5 0A A6 29 67 48 31 67
D4 0B A5 2A 66 49 2E 68
D3 0C A3 2B 65 4A 2D 69
D2 0D 9F 2C 63 4B 2C 6A
D1 0E 9E 2D 5C 4C 2B 6B
CE 0F 9D 2E 5A 4D 2A 6C
CD 10 9B 2F 59 4E 29 6D
CC 11 98 30 56 4F 27 6E
CB 12 97 31 55 50 26 6F
CA 13 90 32 54 51 25 70
C9 14 8F 33 53 52 23 71
C7 15 88 34 52 53 1F 72
C6 16 84 35 51 54 1E 73
C5 17 82 36 4E 55 1D 74
C3 18 81 37 4D 56 1B 75
BC 19 80 38 4C 57 18 76
BA 1A 7C 39 4B 58 17 77
B9 1B 7A 3A 4A 59 10 78
B6 1C 79 3B 49 5A 0F 79
B5 1D 76 3C 47 5B 08 7A
B4 1E 75 3D 46 5C 04 7B
B3 1F 74 3E 45 5D 02 7C
B2 20 73 3F 43 5E 01 7D
