Chapter 7 Disk Array Configuration Setting
IV-59
5. The dialog for renaming a logical disk appears.
Figure 7-52 Dialog for Renaming a Logical Disk
(1) The logical disk name must be unique in the system. (Do not assign the same name twice or more.)
(2) The initial value of the logical disk name field consists of 20 characters; 16 characters specific to the disk array
and 4 characters of the logical disk number.
(3) Any logical disk name that does not conform to the following rules is invalid:
y Number of available characters: 1 to 24 characters
y Available characters: Alphabet: A to Z (a to z)
* Upper- and lower-case characters are distinguished.
Numerals: 0 to 9
Underbar: _
Slash: /
* All the characters must be 1-byte characters.
6. When the logical disk is successfully renamed, the following message is displayed.
Figure 7-53 Message for Successful Completion of Renaming the Logical Disk
