NEC Storage Manager - Logical Disk Screen

Chapter 8 Disk Array Configuration Setting (S100/S1100/S1200/S1300/S2100/S2200/S2300)
IV-149
8
8
8
.
.
.
6
6
6
.
.
.
2
2
2
L
L
L
o
o
o
g
g
g
i
i
i
c
c
c
a
a
a
l
l
l
D
D
D
i
i
i
s
s
s
k
k
k
S
S
S
c
c
c
r
r
r
e
e
e
e
e
e
n
n
n
(1) Description
The LD screen is shown in Figure 8-45. The encircled alphabets in the screen are described below. To know
how to manipulate the screen, refer to (2) “Operation”.
Figure 8-45 LD Screen
(A) PD Group Number
The PD group for performing the LD bind/unbind is specified here. The PD groups existing in the disk array are
displayed in the pull-down list; select one from among them.
The PD group refers to a management aggregate of PDs; therefore, it is impossible to form a configuration
spanning two or more PD groups. LD bind/unbind shall be set within this PD group.
(A)
(B)
