Chapter 8 Disk Array Configuration Setting (S100/S1100/S1200/S1300/S2100/S2200/S2300)
IV-133
8
8
8
.
.
.
3
3
3
.
.
.
1
1
1
S
S
S
p
p
p
a
a
a
r
r
r
e
e
e
B
B
B
i
i
i
n
n
n
d
d
d
On the RANK/Spare Tab screen (Figure 8-28), spare can be bound/unbound by using the popup menu (right-click) or
the buttons on the screen after selecting PDs and RANKs, etc.
Selecting only a single unused PD enables this button, thus making it possible to bind a spare.
Figure 8-29 Spare Bind
Click the [Spare Bind] button to display a message as follows.
Figure 8-30 Spare Bind Confirmation
Select [Yes] to bind a spare.
Select Only a Single Unused Disk.
Button Enabled
To Next Page
