Chapter 2 Overview of Disk Array Configuration Setting
I-21
Chapter 2 Overview of Disk Array
Configuration Setting
This chapter describes an overview of the disk array configuration setting.
The disk array configuration setting is a function for setting the configuration when initializing the disk array and
when extending the physical disks. This operation can be performed by using a GUI from the iSM client.
Figure 2-1 Configuration Setting Outline
A
dministrato
r
Configuration Display Screen
Storage Manage
r
Logical Disk
Disk Array
Controller
(
DAC
)
Disk Enclosure (DE)
Physical
Disk
Disk Array
