Chapter 8 Disk Array Configuration Setting (S100/S1100/S1200/S1300/S2100/S2200/S2300)
IV-107
Figure 8-6 RANK/LD Unbind Check
Select [Yes] to unbind the LDs and RANK.
If LDs in the RANK are in the following states, it is impossible to unbind them.
1. Managed by the Access Control (PORT Mode).
2. Managed by the Access Control (WWN Mode)
3. Pairing is performed.
Execute the unbinding after removing these conditions.
