Chapter 9 Configuration Setting (Common to All Units)
IV-159
failure (busy): Executing other processing
failure (communication): Communication error
failure (protected):
ACOS-4 resource protection error
failure (SDV): Format setting of a snapshot data volume
failure (BV/SV/LV): Format change of BV, SV, or LV
failure (RPL Port): Setting of the replication port
failure (nnh): Other error(s) (nn: Internal error code)
If “failure (communication)” or “failure (nnh)” is displayed in the batch setting process, error may have been
detected after I/O to/from the disk array is ended. Check the iSM client’s main screen to see if settings have been
made for the disk array or not.
(1) For information on the ACOS-4 resource protection error, refer to Appendix G “ACOS-4 Resource Operation
Guard”.
(2) SDV, BV, SV, and LV are volumes used for snapshots. For information about these volumes, refer to the
“Snapshot User's Manual (Function Guide)” (IS030).
(G) By clicking the [Extract Error Line] button after completing the process, only the settings in error are
extracted in the edit box.
(H) In the event of saving the definition file, select [Save As] from the dialog and then save it by specifying any
file name from the save dialog.
Output to a file can be made except the state area at the head of the record
