2-10 System Configuration and Setup
!
Key Legend — The bottom right corner of the screen. These lines display the keys that
move the cursor and select parameters.
Options that are grayed out are not available for the current selection.
Using Keys
The following table lists the BIOS Setup keys and their functions.
BIOS Setup Key Functions
Key Function
↑ ↓
Moves the cursor between the displayed parameters.
PgUp/PgDn Toggles through the current parameter settings.
Tab For some parameter settings, moves the cursor between the
subfields. Also moves the cursor to the next line or selection. For
example, for System Time, Tab moves the cursor from hour to minute
to second.
ESC Exits the current screen and returns to the Main Menu screen. From
the Main Menu screen, displays the prompt, “Quit without saving.”
F3/F4 Changes the screen color.
F10 Saves and exits the BIOS Setup utility.
Checking/Setting System Parameters
The BIOS Setup utility consists of a number of screens, each representing a specific area of the
BIOS. The following tables list the BIOS parameters, their factory default settings, alternate
settings, and a description of each setting. See the item-specific help that appears on each Setup
screen for more details.
The BIOS Setup utility is divided as follows:
!
Standard CMOS Setup
!
Advanced CMOS Setup
!
System Security Setup
!
Power Management Setup
!
Boot Device Setup
!
Peripheral Setup
Resetting System Parameters
To reset all parameters to the default settings, select Auto Configuration with Defaults from the
BIOS Setup Main Menu and press
Enter
. Select
Yes
and press
Enter
.
