NEC VERSA VXi - Parts List

Illustrated Parts Breakdown 5-3
Parts List
The following table lists the NEC Versa VXi notebook FRU parts.
Field-Replaceable Parts List
Item Description
1 LCD Unit Assembly
12.1-inch
13.3-inch
14.1-inch
2 Keyboard
Keyboard (French)
3 Hinge Cover (right)
4 Top Cover Sub Assembly
5 VersaGlide Sub Assembly
6 Audio Board Sub Assembly
7 I/O Board Sub Assembly
8 Main Board Sub Assembly
9 Keyboard Heat Plate Assembly
10 Microphone with attached Cable
11 Li-Ion Battery
NiMH Battery
12 Bottom Base Sub Assembly
13 CD-ROM Drive
14 Speaker and Cable Assembly
15 Diskette Drive
16 CMOS RTC Battery Sub Assembly
17 CD-ROM Rail Bracket
18 DC/DC Board Sub Assembly
19 Hard Disk Drive
6-GB
10-GB
12-GB
18-GB
20-GB
20 Hinge Cover (left)
21 LED/Button Assembly (w/o buttons)
* PC Card Assembly (with main board)
* Memory Module
64-MB
128-MB
* Memory Bay Cover (without plating)
