4
© by NECTA VENDING SOLUTIONS SpA 07-2002 148 03
AVAILABLE ADJUSTMENTS
Fresh brew: coffee or tea dose, water dose. brewing time
and drying time.
Instant: time adjustment for coffee, instant products
and water doses.
Temperature control programmable via software.
CONTROLS
- Presence of cups
- Presence of water
- Fresh brew unit in start position
- Liquid waste container full
- Operating temperature reached
- Position of mobile dispensing spouts
SAFETY DEVICES
- Door switch
- Manual-reset boiler safety thermostats
- Air-break float jamming
- Overflow solenoid valve
- Float for full liquid waste container
- Instant boiler anti-overboiling thermostat
- Boiler sensor short-circuit/failure control
- Timer protection for:
Brewer unit ratiomotor
Fresh-brew product dispensing
- Overheating protection for:
Doser units
Brewer unit ratiomotor
Electric mixers
- Fuse protection for:
Main electrical circuit
Board power supply transformer
Coin mechanism power supply
CAPACITY OF CONTAINERS
Fresh brew tea 5,8 Kg
Fresh brew coffee 5,2 Kg
Sugar 4,4 Kg
Powdered milk 1,4 Kg
Instant coffee 3,9 Kg
Chocolate 3,4 Kg
Soup 3,9 Kg
)~V032(spmaL.NW
slenapgnisitrevdA251
unemnoitceleS38
)lanoitpo(lanretnI18
TECHNICAL SPECIFICATIONS
Power supply voltage 230 V~
Frequency 50 Hz
Installed power 2400 W
Lighting lamps power
CUP DISPENSER
Suitable for cups with a rim diameter of 70-71 mm. with a
capacity of approximately 900 cups;
PAYMENT SYSTEM
The machine is supplied with all electrical prearrangement
for systems with Executive, BDV and MDB protocol, as
well as for installation of 24 V validators.
Beside the coin mechanism housing, suitable space is
provided for the installation (optional) of the most widely
used payment systems.
SALES PRICES
A different price in 4 programmable time periods can be set
for each selection;
the standard setting has the same sales price for all
selections without any time bands.
ENERGY SAVING.
Option of setting the automatic switch-off of lamps and/or
boilers over 3 daily time bands on a weekly basis, to save
electric power during the machine idle periods.
JUG FACILITIES AND FREE VEND
Using a special key, up to 9 freshly brewed drinks can be
dispensed to fill a jug without releasing any cups; alterna-
tively to get free dispensing of normal selections.
COIN BOX
Made of aluminized plate.
Cover and lock are available as accessories.
WATER SUPPLY
From the mains, with a pressure of 5 to 85 N/cm
2
(0,5÷8,5
bar).
