N723-EA Hardware User Guide
Chapter 2 About N723-EA
Copyright © Neoway Technology Co., Ltd. All rights reserved.
13
Wireless rate
GPRS: Max 85.6 Kbps (DL)/Max 85.6 Kbps (UL)
EDGE: Max 236.8 Kbps (DL)/Max 236.8 Kbps (UL)
WCDMA: HSPA+, Max 21 Mbps (DL)/Max 5.76 Mbps (UL)
LTE-FDD: Cat4, no-CA, Max 150 Mbps (DL)/Max 50M bps (UL)
LTE-TDD: Cat4, no-CA, Max 130 Mbps (DL)/Max 30 Mbps (UL)
Transmit power
EGSM900: +33 dBm (Power Class 4)
DCS1800: +30dBm (Power Class 1)
EDGE 900 MHz: +27 dBm (Power Class E2)
EDGE1800 MHz: +26 dBm (Power Class E2)
WCDMA: +23 dBm (Power Class 3)
LTE: +23 dBm (Power Class 3)
Application
interfaces
2G/3G/4G antenna, 4G diversity RX antenna. All of each has a characteristic
impedance of 50 Ω.
Three UART interfaces, one of which is a Debug UART interface.
One USIM interface, 1.8V/3.0V adaptive
One USB 2.0 interface
One SDIO interface, used for WLAN
One SD/eMMC interface, used for SD card or eMMC
One PCM/I2S interface
One RMII interface
One SPI interface, host mode only
One I2C interface, master mode only
Four GPIO interfaces
AT commands
3GPP Release 9
Neoway extended commands
SMS
PDU, TXT
Data
PPP, RNDIS
Protocol
TCP/TCPS, UDP, HTTP/HTTPS, FTP, MQTT
Certification
approval
CE, RoHS
