N723-EA Hardware User Guide

Chapter 5 Application Interfaces

N723-EA provides one PCM/I2S interface, supporting 1.8 V level. The following figure shows the

reference design of the I2C interface:

Figure 5-26 Reference design of the I2S

Codec

N723-EA

Module

I2S_TX

I2S_RX

I2S_WS

I2S_SCLK

GND

I2S_DIN

I2S_DOUT

I2S_SYNC

I2S_SCLK

GND

If you need to use the PCM/I2S function, contact Neoway FAEs.

5.3.6 SPI

Signal

I/O

Function description

SPI_CLK

Clock signal

SPI_MISO

Output of the slave device and input of the master device

SPI_MOSI

Input of the slave device and output of the master device

SPI_CS_N

Chip select signal of the slave device

The SPI interface supports 1.8 V and only master mode. The following figure provides the SPI

connection.
