N723-EA Hardware User Guide

Chapter 7 RF Characteristics

7.2 TX Power and RX Sensitivity

Table 7-2 N723-EA RF transmit power

Band

Max power

Min. power

EGSM900

33 dBm±2 dB

5 dBm±5 dB

DCS1800

30 dBm±2 dB

5 dBm±5 dB

WCDMA B1

23 dBm+1/-3 dB

<-50 dBm

WCDMA B5

23 dBm+1/-3 dB

<-50 dBm

WCDMA B8

23 dBm+1/-3 dB

<-50 dBm

FDD LTE B1

23 dBm±2 dB

<-39 dBm

FDD LTE B3

23 dBm±2 dB

<-39 dBm

FDD LTE B5

23 dBm±2 dB

<-39 dBm

FDD LTE B7

23 dBm±2 dB

<-39 dBm

FDD LTE B8

23 dBm±2 dB

<-39 dBm

FDD LTE B20

23 dBm±2 dB

<-39 dBm

FDD LTE B28

23 dBm±2 dB

<-39 dBm

TDD LTE B38

23 dBm±2 dB

<-39 dBm

TDD LTE B40

23 dBm±2 dB

<-39 dBm

TDD-LTE B41

23 dBm±2 dB

<-39 dBm

Table 7-3 GSM RX sensitivity of N723-EA

Band

Receiving sensitivity

EGSM900

≤-108 dBm

DCS1800

≤-108 dBm

Table 7-4 N723-EA WCDMA RX sensitivity

Band

Receiving sensitivity

WCDMA B1

≤-108 dBm

WCDMA B5

≤-108 dBm

WCDMA B8

≤-108 dBm
