N723-EA Hardware User Guide

Chapter 4 Module Pins

Leave this pin floating if it is not used.

GPIO_13

GPIO with interrupt

Pull-down by default.

Leave this pin floating if it is not used.

Antenna Interfaces

ANT_MAIN

Main antenna

50 Ω impedance characteristics

ANT_DIV

Diversity antenna

50 Ω impedance characteristics

Other Interfaces

RING

Incoming call indicator

control

Leave this pin floating if it is not used.

NET_LIGHT

Network indicator control

Leave this pin floating if it is not used.

RESERVED

32, 50, 53, 73, 80, 88, 89, 92

Used for function extension or the function

not open to users. These RESERVE pins

might have different definitions or functions.

Ensure that all RESERVED pins are left

floating.
