Chapter 9 Mounting

⚫

Ramp up rate: 1 to 4 °C/sec

⚫

Ramp down rate: -3 to -1 °C/sec

⚫

Soaking zone: 150-180 °C, Time: 60-100 s

⚫

Reflow zone: >220 °C, Time: 40-90 s

⚫

Peak temperature: 235 - 245°C

For information about cautions in storage and mounting, refer to

Neoway_Reflow_Soldering_Guidelines_For_Surface-Mounted_Modules.

When manually desoldering the module, use heat guns with great opening, adjust the temperature to

245 °C (depending on the type of the solder paste), and heat the module till the solder paste is melted.

Then remove the module using tweezers. Do not shake the module at high temperatures while

removing it. Otherwise, the components inside the module might get misplaced.
