Neptronic SKE4-E Series - General Menu Settings (Continued); System Status Parameters

SKE4-E Steam Humidifier
Installation Instructions and User Manual
www.neptronic.com
Page | - 48 -
Sub-Menu
Setting
Default
Range
(* indicates no configuration; display only)
Description/Notes
Physical IO
WtrLeakDet:
Ok
* (Ok, Leak)
Displays whether a water leak has been detected. If Leak is displayed, it indicates that there is a leak within the water line.
WtrLvlLow:
Current value
* (Inactive, Active)
Displays the status of the resistive low water level sensor.
WtrLvlHigh:
Current value
* (Inactive, Active)
Displays the status of the resistive high water level sensor.
WaterTemp:
Current value
* (min: 0.00°C, max: 125.00°C) Units: C, F
Displays the temperature of water in the evaporation chamber.
FoamSensor:
NoFoam
* (NoFoam, Foam)
Displays whether foam has been detected within the evaporation chamber. If Foam is displayed, it indicates that the Anti-Foaming Energy Conservation (AFEC) system has detected foam. The humidifier will drain for a few minutes and return to normal operation.
ThermalCutout:
Closed
* (Closed, Open)
Displays the status of the high temperature switch. If Open is displayed, it indicates that an abnormal temperature has been sensed.
SSRTemp:
Current value
* (min: -20.00°C, max: 100.00°C) Units: C, F
Displays the temperature measured on the solid-state relay.
CabinetTemp:
Current value
* (min: -20.00°C, max: 100.00°C) Units: C, F
Displays the temperature measured inside of the cabinet. (Only appears for units with the weather proof enclosure.)
CurrentSensor1:
Current value
* (min: 0A, max:150A)
Displays the measured electric current in the first current sensor. (Only appears when using a current sensor.)
CurrentSensor2:
Current value
* (min: 0A, max:150A)
Displays the measured electric current in the second current sensor. (Only appears when using two current sensors.)
ContactorsFuse:
Normal
* (Normal. Blown Fuse)
Displays the current status of the PCB fuse. If Blown Fuse is displayed, the fuse must be replaced.
PowerOutFdbck:
Current value
* (min: 0.00%, max: 100.00%)
Displays the feedback value of power output analog output.
AlarmWarnRelay:
Current value
* (Off, On)
Displays the status of the alarm warning relay.
ServiceWarnRelay:
Current value
* (Off, On)
Displays the status of the service warning relay.
WtrLvlValve:
Current value
* (Off, On)
Displays the status of the water level sensor supply valve.
TankWtrValve:
Current value
* (Off, On)
Displays the status of the evaporation chamber water supply valve.
DrainCoolValve:
Current value
* (Off, On)
Displays the status of the internal drain cooler valve.
DrainPump:
Current value
* (Off, On)
Displays the status of the drain pump.
DrainValve:
Current value
* (Off, On)
Displays the status of the normally open drain valve. (Only appears for units with the weather proof enclosure.)
MainContactor:
Current value
* (Off, On)
Displays the status of the main contactor.
HeaterStage1:
Current value
* (Off, On)
Displays the status of the first stage contactor. (Only appears based on humidifier model and configurations.)
HeaterStage2:
Current value
* (Off, On)
Displays the status of the second stage contactor. (Only appears based on humidifier model and configurations.)
HeaterStage3:
Current value
* (Off, On)
Displays the status of the third stage contactor. (Only appears based on humidifier model and configurations.)
SDUFan:
Current value
* (Off, On)
Displays the status of the SDU fan. (Only appears for humidifiers having the SDU option.)
HeaterSSRStage:
Current value
* (min: 0.00%, max: 100.00%)
Displays the heater vernier stage output value.
WaterLevel:
Current value
* (min: 0.0%, max: 120.0%)
Displays the percentage of water remaining in the evaporation chamber.
