Getting Started Using FirstGear for the Model RT328 ISDN Router
2-2 Hardware Installation
Key:
1 = ISDN wall connection
2 = NETGEAR Model RT328 ISDN Router
3 = AC power adapter
4 = AUI connection
5 = UTP (10BASE-T) LAN connection to the PC or hub
6 & 7 = Analog device (telephone, fax, or modem)
Figure 2-1. Router connections
Warning:
Several of the connectors and connection cables are very similar to one
another. To prevent serious damage to the router, it is important that you use the specified
cable for each connection and that you connect the ports correctly.
AUI
LAN
POWER
16VAC
UTP
MGR
ISDN-U PHONE 1 PHONE 2
7633EA
7
1
3
5
6
2
4
RT328.BK Page 2 Wednesday, August 6, 1997 11:14 AM
