Wireless-N 150 ADSL2+ Modem Router DGN1000 User Manual
A-4 Factory Settings, Technical Specifications, and Wall Mounting
v1.1, January 2010
To wall mount the wireless modem router:
1. Drill holes in the wall where you will wall-mount the router.
Holes should be 9.5 in.
(24.1 cm) center to center.
Figure A-1
2.
Figure A-2
Install wall anchors in the holes.
Use pan head Phillips woodscrews, 3.5 x 20 mm (diameter x length, European) or #6 type
screw, 1 inch long (US).
