Current
Output
range/channel
Charge: 30mA~30A
Discharge: 30mA~30A
Accuracy
± 0.02% of range(full range)
Stability
0.025%
Power
Output
power/channel
600W
Stability
0.05%
Time
Current response
The hardware response time from current to 30A is 30ms
Step time range
1~65535 minutes/step
Time format 00:00:00(h, min, s)
Data
record
Condition
TimeΔt: (0.01s~60000s)
VoltageΔU: (12mV~20V)
CurrentΔI: (7.5mA~30A)
Frequency
100Hz
Charge
Charge mode
CC, CV, CCCV
Stop condition
Voltage, Current, Relevant time, Capacity
Discharge
Discharge mode
CC,CP
Stop condition
Voltage, Current, Relevant time, Capacity
Cycle
Cycle test range
1~65535 times
Stpes per cycle
255
Loop nesting
With nested loop function, supports a maximum of 4 layers of nesting
Protection
Security
protection and
exception
protection
Data protection for power outage
Safety protection conditions: Voltage upper/lower limitation, current
upper/lower limitation, delay time. Exception protection conditions: Maximum
CC charge/discharge current fluctuation, Current falling range for CV charging,
Amplitude of voltage rise during CC charge, Amplitude of voltage drop during
CC discharge.
Hardware
Anti-reverse connection protection, reverse connection warning
Channel feature
Constant current source and constant voltage source adopt independent double
closed loop structure
Channel control mode
Independent control
Voltage and current
sampling
4 wire connection
Noise
<80dB
Host computer
communication
TCP/IP
Data output
EXCEL、TXT、Chart
Communication port
Ethernet 10/100M
Channels number/unit
8
Requirement of operation environment
Items
Parameters
Operation temperature range
10℃~40℃
Storage temperature range
10℃~45℃
Working environment
humidity
30% ~ 80% RH(No condensation)
