Chapter 8 Build Test Tutorial
Introduction of step editor interface
Figure 8-1 Step file storage path
1 Test file storage (set the root directory and the project folder)
2 File operation (Add, save, save as, delete)
3 List of step files under the current project (selected as currently displayed step files)
4 Main step zone (This includes test flow, variable management, editing DBC, display settings, record settings, and
NG Settings)
5 Protection condition (each step is a separate protection parameter)
6 Record condition (each step is a separate recording parameter)
7 Test information (relevant description of the tests)
The following describes the saving path of step files and the relationship between function interfaces and step files.
Figure 8-2 Step File storage path
