socket
6 Power supply port
It can be connected to 220V power supply and 110V power supply.
7 Air outlet of
radiator fan
For internal cooling.
Technical specifications of BTS9000 series equipment are shown in Form 3:
Form 3: Technical specifications for BTS9000 Series equipment (for example, CT-9004-5V5A)
Power source Input
range
AC 220V +10% / -20%, 50Hz
Output
power/channel
25W
Voltage
range/channel
0.7 V~5V
Current range
Range 1: 0.1uA---150uA, Range 2: 140uA---5mA, Range 3: 4.5mA---150mA, Range
4: 140mA---5A
Current resolution
16bits(Range5A: 0.08mA, Range150uA: 3nA)
Voltage resolution
16bits(0.08mV)
Time resolution
1μS
Data record
frequency
1000Hz(constant charge/discharge mode)/individual pulse recording(GSM pulse
mode)
Current test/output
accuracy
±0.2‰ FS
Voltage test/output
accuracy
±0.2‰ FS
Current stability
±0.25mA;(Range: 5A)
Voltage stability
±0.25mV
Step types
Charge: CC, CV, CCCV, CP
Discharge:CC, CP, CR, GSM Pulse
Rest, Pause, Cycle
Step counts
1~255
Single step time
65535s
Loop nesting
4 layers
Pulse time control
accuracy
±1μS
Minimum pulse
width
400μS
Single step
protection condition
Supported
Types of protection
condition
Upper limitation: voltage/current/capacity
Lower limitation: voltage/current
Fluctuation protection: Voltage/current
Charge and discharge slope
Hardware response
time
<=100μS(10%to90%or90%to10%)
Calibration
frequency
3 month
Operation
environment
25±5℃(Accuracy guarantee),  25±20℃(Ultimate-use temperature)
Storage environment
0~60℃
Local data record
capacity
1GBperchannel
Communication
10/100MEthernet
